Dual Peristaltic Pump
Code  NC0060-0010
Classification  蠕動幫浦
Size
Order 加入購物車
Print
PRODUCT DETAIL
Multi-Peristaltic Pump

Tetrad peristaltic pump (Cat. No.: MFU-02) is a digital microprocessor version, providing a much better accurate rpm control. It is equipped with four peristaltic pumps. Each pump can be operated separately due to individual control mechanism. In addition, a timer is also equipped with the alarm function. MFU-02, like other mode of peristaltic pump product, meets the most application requirements, and remain all the features of MFU-01.



Features
  • Compact size
  • Digital precise control
  • Easy load pump header
  • Four peristaltic pumps
  • Individual controller for each pump
  • Wide applications
  • Reversible for purging



Specification
  • Rpm / Inc: 0.1 - 100.0 / 0.1
  • Motor: Stepping motor
  • Speed Control: ±1%
  • Number of Peristaltic Pump: 4
  • Number of Rollers: 3
  • Maximum Pump Speed: 100rpm
  • Variable Flow Rate: 0.6~380ml / min
  • Operating Temperature: Ambient to 40℃
  • Unit Material: Printed metal
  • Unit Dimension: 265 x 340 x 180 (W x L x H)
  • Rated Voltages: 100 - 240 V
  • Weight: approx. 7.5kg

Sillcon Tube and Typical Rate

Silicon Tubing
Cat. No.

Tube I.D.
Size('')

10 rpm
(ml/Rev.)

50 rpm
(ml/Rev.)

100 rpm
(ml/Rev.)

MU-S13

1/32

0.6
3

6

MU-S14

1/16

2.1
10.5

21

MU-S16

1/8

8
40

80

MU-S17

1/4

17
85

170

MU-S18

3/8

28
140

280

MU-S25

3/16

38
190

380



Ordering Information

Cat. No.

 Description

MFU-02

Tetrad Peristaltic Pump
Accessories

MU-S13

Silicon tube I.D. 1/32''25ft

MU-S14

Silicon tube I.D. 1/16''25ft

MU-S16

Silicon tube I.D. 1/8''25ft

MU-S25

Silicon tube I.D.3/16''25ft

MU-S17

Silicon tube I.D.1/4''25ft
MU-S18

Silicon tube I.D.3/8''25ft
